Will it work with your system?
Works well with
- Electric floor heat
- Room-by-room electric heat
Check first if you have
- Furnaces, boilers and heat pumps (24 V)
- Loads above its rating
What it controls
The Mysa IN-FLOOR V1-0 Floor Heating Thermostat is a floor heating for electric heat that runs at line voltage (240 V per the maker).
Its maker rates it for 3,800 W. At 240 V that covers heaters totalling about 3,800 watts (watts = amps × volts). Check your heaters' load.
As a floor-heating thermostat it typically works with a floor sensor; the floor system's maker specifies which thermostats it supports, and that comes first.
Connectivity: Wi-Fi, so the schedule and setpoint can be changed from a phone.
Line voltage can kill: switch the breaker off and confirm it's dead before touching the wires, and use a licensed electrician if you're unsure. Line vs low voltage.
Also on the listing: dimensions of 0.78 in (D) x 3.03 in (W) x 4.56 in (H), a weight of 499 g and a led.
Compatibility and specs
These come from the maker's listing for this exact model; the source of each is marked. Anything the maker leaves out is marked not stated.
| Model number | IN-FLOOR | Retailer |
|---|---|---|
| Model name | Mysa Smart Thermostat for Electric In-Floor Heating | Retailer |
| Dimensions (seller) | 0.78"D x 3.03"W x 4.56"H | Retailer |
| Works with | Amazon Alexa, Android, Apple HomeKit, Google Assistant, iOS | Retailer |
| Features (seller) | Daylight Savings Time Ready, Lockable, Programmable, Temperature Display, Vacation Mode | Retailer |
| Connectivity | Wi-Fi | Retailer |
| Power | Electricity,Electric | Retailer |
| Voltage | 240 V | Retailer |
| Display | LED | Retailer |
| Mounting / installation | Wall Mount | Retailer |
| Max load | 3800 W | Retailer |
| Product weight | 499 g | Retailer |
| Material | Plastic | Retailer |
| Works with systems | works with 120-240V electric in-floor heating systems and includes a built-in Class A GFCI | Retailer |
| Schedule | Programmable | Retailer |
Strong points and weak points
Strong points
- Rated 3,800 W
- Wi-Fi control
- 240 V
Weak points
- Household-voltage wiring
- One thermostat per heater circuit
Wiring and install notes
- Compatibility statements are the maker's own. Confirm with the maker's compatibility checker, turn the power off before wiring, and leave line-voltage and furnace work to a licensed electrician or HVAC technician.
Thermostats to compare it with
FAQ
How many heaters can the Mysa IN-FLOOR V1-0 Floor Heating Thermostat control?
Can the Mysa IN-FLOOR V1-0 Floor Heating Thermostat run a furnace or heat pump?
Other line-voltage thermostats with similar wiring
Our take
A fit for electric floor heat.
Where to get it
The link goes to this exact model's listing. Check that the box includes the trim plate or C-wire adapter you need, and confirm your wiring with the maker's compatibility checker before you order.
